序号 No. |
轮胎规格 Size of Tire |
轮辋型号 Rim Size |
花纹编号 Pattern No | 外直径 Outside Diameter ±5mm | 断面宽度 Section Width ±5mm | 轮胎重量 Net Weight(Kg) ±1.5%kg |
10 驱动轮 Driving | 最 平衡式叉 km/h 转向轮 Steering | 大负荷 车Counte 1 驱动轮 Driving | Max Load( r Balance 6km/h 转向轮 Steering | Kg) d lift Truck 25 驱动轮 Driving | s km/h 转向轮 Steering | 其他工业车辆 Other Industria vehicles |
4.00-8 | 3.00/3.75 | B701/B706 | 410/423 | 115/120 | 14.5/12.2 | 910 | 700 | 830 | 640 | 765 | 590 | 590 | |
2 | 5.00-8 5.50-15 | 3.00/3.50/3.75 4.50 | B701/B705 | 466 | 127 | 18.40 | 1255 | 965 | 1145 | 880 | 1060 | 815 | 815 |
3 | B701 | 666 | 144 | 37.00 | 2525 | 1870 | 2415 | 1790 | 2195 | 1625 | 1495 | ||
4 5 | 6.00-9 6.00-15 | 4.00 4.50 | B701b705B788 B701 | 533 694 | 140 148 | 26.80 41.20 | 1975 2830 | 1520 2095 | 1805 2705 | 1390 2000 | 1675 2455 | 1290 1820 | 1290 1675 |
6 | 6.50-10 | 5.00 | B701/B705B788 | 582 | 157 | 36.00 | 2715 | 2090 | 2485 | 1910 | 2310 | 1775 | 1775 |
7 | 7.00-9 | 5.00 | B701 | 550 | 164 | 34.20 | 2670 | 2055 | 2440 | 1875 | 2260 | 1740 | 1740 |
8 | 7.00-12 | 5.00 | B701/B705/B788 | 663 | 163 | 47.60 | 3105 | 2390 | 2835 | 2180 | 2635 | 2025 | 2025 |
9 10 | 7.00-15 7.50-15 | 5.50/6.00 5.50 | B701 B701 | 738 768 | 178 188 | 60.00 75.00 | 3700 3805 | 2845 2925 | 3375 3470 | 2595 2670 | 3135 3225 | 2410 2480 | 2410 2480 |
11 | 7.50-16 | 6.00 | B701 | 805 | 180 | 74.00 | 4400 | 3385 | 4025 | 3095 | 3730 | 2870 | 2870 |
12 | 8.25-12 | 5.00 | B701 | 732 | 202 | 71.80 | 3425 | 2635 | 3125 | 2405 | 2905 | 2235 | 2235 |
13 | 8.25-15 | 6.50 | B701/B705 | 829 | 202 | 90.00 | 5085 | 3910 | 4640 | 3570 | 4310 | 3315 | 3315 |
14 15 | 15*4%-8 16*6-8 | 3.00 4.33 | B701/B705 B701/B705 | 383 416 | 107 156 | 9.40 16.90 | 1005 1545 | 775 1190 | 915 1410 | 705 1085 | 850 1305 | 655 1005 | 655 1005 |
16 | 18*7-8 | 4.33 | B701/B705 | 452 | 155 | 20.80 | 2430 | 1870 | 2215 | 1705 | 2060 | 1585 | 1585 |
17 | 18*7-9 | 4.33 | B701/B705 | 452 | 155 | 19.90 | 2230 | 1780 | 2150 | 1615 | 2005 | 1505 | 1540 |
18 | 21*8-9 | 6.00 | B701/B705 | 523 | 180 | 34.10 | 2890 | 2225 | 2645 | 2035 | 2455 | 1890 | 1890 |
19 20 | 23*9-10 23*10-12 | 6.50 8.00 | B701/B705 B701/B705 | 595 592 | 212 230 | 51.00 51.20 | 3730 4450 | 2870 3425 | 3405 4060 | 2620 3125 | 3160 3770 | 2430 2900 | 2430 2900 |
21 | 27*10-12 | 8.00 | B701/B705 | 680 | 236 | 74.70 | 4595 | 3535 | 4200 | 3230 | 3900 | 3000 | 3000 |
22 | 28*9-15 | 7.00 | B701/B705B788 | 700 | 230 | 63.00 | 4060 | 3125 | 3710 | 2855 | 3445 | 2650 | 2650 |
23 | 28*12.5-15 | 9.75 | B705 | 706 | 300 | 86.00 | 6200 | 4770 | 5660 | 4355 | 5260 | 4045 | 4045 |
24 25 | 140/55-9 200/50-10 | 4.00 6.50 | B705 B701/B705 | 380 458 | 130 198 | 10.50 25.20 | 1380 2910 | 1060 2240 | 1260 2665 | 970 2050 | 1170 2470 | 900 1900 | 900 1900 |
26 | 250-15 | 7.00/7.50 | B701/B705 | 726 | 235 | 73.60 | 5595 | 4305 | 5110 | 3930 | 4745 | 3650 | 3650 |
27 | 300-15 | 8.00 | B701/B705 | 827 | 256 | 112.50 | 6895 | 5305 | 6300 | 4845 | 5850 | 4500 | |
28 | 355/65-15 | 9.75 | B701 | 825 | 302 | 135.00 | 7800 | 5800 | 7080 | 5310 | 6000 | 4800 | 5450 |
