序号 No |
轮胎规格 Sizeof Tire |
轮辋型号RimSize |
花纹编号PatternNo | 外直径 OutsideDiamete ±5mm | 断面宽度 SectionWidth ±5mm | 轮胎重量 Net Weight(Kg) ±1.5%kg | 最大负荷 MaxLoad(Kg) 其他工业车辆OtherIndustniavehicles16km/h |
1 | 2.00-8(12*4) | 2.50/3.00 | B700/B706/B707 | 318/310 | 103/100 | 5.00 | 380 |
2 | 3.00-5 | 2.15 | B713/B716 | 268/250 | 77/72 | 3.70 | 330 |
3 4 | 3.20-8 3.50-5 | 3.00 3.00 | B706 B701 | 328 300 | 110 100 | 6.20 6.30 | 520 380 |
| 3.60-8 | 3.00 | B706 | 368 | 110 | 8.60 | 600 |
6 | 4.00-4 | 2.50C | B701 | 300 | 100 | 6.00 | 380 |
7 8 | 4.00-8(Wide)4.00-8 | 3.75 3.00/3.75 | B706 B701/B706 | 423 410 | 120 115 | 14.50 12.20 | 730 695 |
| 16*5-9 | 3.50/4.00 | B706 | 404 | 126 | 12.50 | 710 |
10 | 300*125 | FB | B700 | 302 | 125 | 11.30 | 910 |
11 | 350*100 | FB | B700 | 352 | 100 | 12.30 | 850 |
