序号 NO |
轮胎规格 SIZE OF TIRE |
带孔(是/否) TIRE WITH HOLE (YES/NO) |
花纹编号 PATTERN NO. | 外直径 OUTSIDE DIAMETER ±5MM | 断面宽度 SECTION WIDTH ±5MM | 轮胎重量 NET WEIGHT(KG) ±1.5%KG | 最大负荷 MAXLOAD(KG) 其他工业车辆 OTHER INDUSTRIAL VEHICLES 16KM/H |
1 | FB10*16.5(30*10-16) | YES | B708 | 788 | 250 | 116 | 3700 |
2 | FB12*16.5(33*12-20) | YES | B708 | 840 | 275 | 140 | 4500 |
3 4 | FB16/70-20 FB16/70-20(经济型) | YES YES | B708 B708 | 1060 940 | 400 330 | 329 216 | 8830 6620 |
5 | FB38.5*14-20(14*17.5) | YES | B708 | 966 | 350 | 246 | 7070 |
6 | FB385/65-24(385/65-22.5) | YES | B708 | 1062 | 356 | 290 | 7390 |
7 8 | FB445/65-24(445/65-22.5) FB14.00-24 | YES NO | B708 B701 | 1152 1340 | 428 328 | 394 461 | 10040 10700 |
9 | FB17.5-25 | YES | B709 | 1368 | 458 | 650 | 13400 |
10 | FB18.00-25 | YES | B711 | 1620 | 500 | 960 | 15795 |
11 12 | FB20.5-25 FB23.5-25 | NO YES | B709 B709 | 1455 1620 | 500 580 | 950 1040 | 17470 23400 |
13 | FB26.5-25 | YES | B709 | 1715 | 642 | 1395 | 29260 |
14 | FB29.5-25 | B709 | 1840 | 730 | 1780 | 34390 |
