序号 NO. |
轮胎规格 SIZE OF TIRE |
轮辋型号 RIM SIZE |
花纹编号 PATTERN NO. | 外直径 OUTSIDE DIAMETER ±5MM | 断面宽度 SECTION WIDTH ±5MM | 最大负荷 MAXLOAD(KG) 其他工业车辆 OTHER INDUSTRIAL VEHICLES 16KM/H |
1 | 8.25-20 | FB | B701 | 976 | 217 | 4230 |
2 | 10.00-20 | FB | B701 | 1041 | 248 | 5300 |
3 | 12.00-24 | FB | B701 | 1218 | 300 | 7690 |
4 5 | 14.00-20 14.00-24 | FB FB | B706 B701 | 1250 1340 | 316 328 | 9495 10700 |
6 | 16.00-25 | FB | B711 | 1460 | 410 | 13340 |
7 | 17.5-25 | FB | B709 | 1368 | 458 | 13400 |
8 | 20.5-25 | FB | B709 | 1455 | 500 | 17660 |
9 10 | 18.00-33 54*26 | FB FB | B715 B715 | 1840 1370 | 450 660 | 18380 23130 |
11 | 55*18-34 | FB | B715 | 1410 | 450 | 15050 |
12 | 1510*470 | FB | B715 | 1516 | 470 | 16120 |
13 | 1098*500 | FB | B711 | 1098 | 500 | 14235 |
